Farmall A, AV and B, BN Tractor Parts Catalog TC-26F provides a comprehensive listing of every part on the tractor. It includes exploded drawings for correct assembly and identification, part numbers, part names, descriptions, and dimensions necessary for proper part identification. Additionally, it specifies part quantities used per vehicle, model application, and the year a part was used.
This parts catalog is valuable for both professional mechanics and DIY enthusiasts. It offers instant access without any waiting time. The format of the manual is available in .PDF file.
Farmall A Specifications
Model history
Model introduced 1939
Model discontinued 1947
Model status Discontinued
No. produced 128,246 (includes Farmall A-AV, International A)
Preceded by McCormick-Deering Farmall F-14
Superseded by McCormick Farmall Super A
Engine Specification
Engine make International
Engine model C-113
Fuel type distillate
Power hp 16 belt, 15 drawbar
Governed rpm 1400
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3 in
Stroke in (mm) 4 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA
Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 4
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 4.00-15 4-ply
Rear 9-24 4-ply (8-24 standard)
Tractor Dimensions
Length (inches/metres) 106 in
Width (inches/meters) 56 in
Height (inches/meters) 63 in
Weight (nominal) lb/kg 1780 lb
Turning circle (nominal) inches/meters 18 ft
Wheelbase 71 in
More info
Factories Tractor Works, Chicago, Illinois
Plow rating 1-14"
Nebraska Tests No. 330
Approximate Cost new in (year) $542 (1941), $1295 (1947)
